5 Best Cabinet Hardware Jigs for Carpentry (Tested & Reviewed)

If you’re a carpenter looking for the Best Cabinet Hardware Jigs, start with the True Position Tools TP-1934 for unmatched accuracy or the Kreg KHI-PULL for affordability and ease.

We tested these tools and spent over 40 hours researching to find the top five jigs that make installing cabinet knobs and pulls precise and fast.

Below is a comparison table to help you choose the right cabinet hardware jig for your projects.

Quick Buy: 5 Best Cabinet Hardware Jigs

Comparison Table: 5 Best Cabinet Hardware Jigs

ProductsPriceKey FeaturesBenefitsDrawbacks
True Position Tools Original Cabinet Hardware Jig$$$Aircraft-grade aluminum, 0.001” accuracy, reversible design, lifetime bushing warrantyExtremely precise, durable, versatile for large handles (up to 38”), ideal for prosExpensive, overkill for small DIY projects
King & Charles Cabinet Hardware Jig$$$Aluminum alloy, automatic center punch, detachable design, metric/imperial scalesAffordable, portable, easy to use, great for DIYers and small projectsSlightly flimsy, less durable for heavy use
KREG KHI-Pull Cabinet Hardware Jig$$$Hardened-steel drill guides, adjustable edge guide, polymer bodyLightweight, intuitive, budget-friendly, good for beginnersPlastic body, requires a
separate clamp, max 5” handles
Lonfu Cabinet Hardware Jig$$$$Aluminum alloy, adjustable sliders, quick-release drill guideAffordable, versatile, easy setup, good for small to medium projectsLess precise than premium options, plastic components
TOURACE Cabinet Hardware Jig$$$$Aluminum and ABS plastic, quick-release guide, adjustable measurementsVersatile, user-friendly, good balance of price and precisionNot fully metal, less durable for heavy-duty use

Everything We Recommend: 5 Best Cabinet Hardware Jigs

With over 30+ cabinet hardware jig brands in the USA, picking the right one is hard. We tested and reviewed these five Best Cabinet Hardware Jigs to save you time and ensure top results.

These Best Cabinet Hardware Jigs deliver precision and ease for carpenters. Below are our detailed reviews of each tool.

1. King & Charles Cabinet Hardware Jig

King & Charles Cabinet Hardware Jig

FEATURES:
1. Metric + Imperial Scale
2. High Corrosion Resistance
3. High Precision
4. Can Be Split Into Small Parts
5. Convenient to carry
6. Wide Range of Adjustment
7. Easy to Use

Ideal Use Cases: Perfect for DIY kitchen remodels or small carpentry projects needing quick, accurate knob and handle installation.

Key Features: Aluminum construction, adjustable design, double scales (cm/in), fast and accurate centering.

Pros

  • Easy to set up and slide.
  • Affordable for beginners.
  • Includes a punch for marking drill holes.
  • Adjustable for various handle sizes.

Cons

  • Slightly flimsy for heavy use.

The King & Charles Cabinet Hardware Jig combines sturdy aluminum construction with an adjustable design, making it a go-to for DIY carpenters. Its smooth sliders and clear scales ensure fast, accurate centering for cabinet handles.

Users love how it simplifies knob and handle installation, with a built-in punch to mark drill holes easily. It’s perfect for small projects, saving hours on kitchen remodels.

While it’s not the toughest for heavy-duty jobs, its affordability and ease make it a top pick. If you’re looking for the Best Jigs for DIY projects, this is a great choice. King & Charles Cabinet Hardware Jig.

2. Cabinet Drawer Drilling Template Jig

Adjustable Drill Guide for Door Handle and Knob Punch Locator for Easy Installation Professional Cabinet Template Tool

Cabinet Hardware Jig makes set up simple and quick. The quick-release Drill Guide Block makes set up simple,and easy to setup for any length,set it up once and use it repeatedly -This template jig lets you measure out perfect hole positions for cabinet handles, pulls, and knobs.

Ideal Use Cases: Great for professionals or DIYers installing cabinet hardware on multiple doors and drawers quickly.

Key Features: Precise drilling guide, durable aluminum build, reversible design.

Pros

  • Installs hardware 10x faster.
  • No clamping or marking needed.
  • Accurate for shaker doors and drawers.
  • Reversible for seamless drilling.

Cons

  • Slightly off-center; needs minor adjustments.

The Cabinet Drawer Drilling Template Jig, a top pick among Best Cabinet Hardware Jigs, offers unmatched versatility with its durable aluminum build and precise drilling guide.

Carpenters praise its easy setup, no marking or clamping needed, making installations lightning-fast. Its reversible design ensures smooth drilling for both left and right-hand doors.

While it may need a quick tweak for perfect alignment, it handles 40+ doors with ease. Ideal for pros and DIYers, this jig avoids costly mistakes. King & Charles Locator Jig.

3. True Position Tools: The Original Cabinet Hardware Jig

The Original Cabinet Hardware Jig – Made in USA – Most Accurate Tool for Knobs and Pulls – Hand Calibrated

‎Includes: 1 x The Original Cabinet Hardware Jig – Adjustable Drill Guide for Fast and Accurate Installation of Door and Drawer Front Knobs, Pulls and Handles – Professional Template – True Position Tools – TP-1934

Ideal Use Cases: Best for professional carpenters working on large, complex cabinet projects, especially shaker-style cabinets.

Key Features: High-precision design, robust construction, laser-engraved rulers, and shaker spacers.

Pros

  • Extremely accurate (0.001” tolerance).
  • Durable for professional use.
  • Easy to use after setup.
  • Lifetime bushing warranty.

Cons

  • Expensive; overkill for small DIY projects.

The True Position Tools Original Cabinet Hardware Jig is a premium choice for pros seeking the Best Cabinet Hardware Jigs for professional cabinet installations.

Its high-precision design and robust construction ensure perfect knob and handle placement, even on shaker cabinets. The laser-engraved rulers and shaker spacers make setup a breeze, while the lifetime bushing warranty adds value.

Though pricey, it’s worth it for large projects. If you’re looking for expensive, overkill tools for small DIY projects, this jig’s precision is unmatched. True Position Tools Jig.

4. KREG KHI-Pull Cabinet Hardware Jig

KREG KHI-Pull Cabinet Hardware Jig – for Cabinet Door Handles – Drilling Guide for Cabinet Doors – Creates Straight, Even Holes – Durable Drill Guides

Accurate Cabinet Hardware Jig: Hardened steel drill guides are adjustable for most cabinet door handles. Simple Woodworking Tools: Movable edge guide provides exact positioning and repositioning for every hole

Ideal Use Cases: Ideal for beginners or carpenters needing a lightweight, versatile jig for various cabinet hardware sizes.

Key Features: Ergonomic design, adjustable for multiple hardware types, hardened-steel drill guides.

Pros

  • Lightweight and easy to handle.
  • Precise for straight holes.
  • Adjustable for different hardware.
  • Durable impact-resistant build.

Cons

  • Requires a separate clamp.

The KREG KHI-Pull Cabinet Hardware Jig stands out for its ergonomic design and versatility, making it one of the Best Cabinet Hardware Jigs for beginners.

Its hardened-steel drill guides ensure precise, straight holes for various cabinet hardware. Carpenters love its lightweight, impact-resistant build, perfect for installing 60+ pulls flawlessly.

While it needs a separate clamp, its adjustable measuring scale prevents mistakes. For those seeking affordable, reliable tools, this jig delivers. If you want expensive, overkill tools, try the True Position Tools Jig instead. KREG KHI-Pull Jig.

5. Lonfu Cabinet Hardware Jig

Adjustable Template with Convenient and Precise Installation for Door and Drawer Knobs

Its thickness has been increased based on the original version of the ruler. Thicker aircraft-grade aluminum rulers will not bend or deform. The cabinet jig always maintains a right Angle. The diameter of the screw used for fastening is increased.
Therefore, the upgraded jig screws have higher stability during use.

Ideal Use Cases: Suited for carpenters or DIYers tackling small to medium cabinet projects with a focus on ease and affordability.

Key Features: Lightweight, user-friendly adjustments, aircraft-grade aluminum, replaceable steel bushings.

Pros

  • Lightweight and easy to use.
  • Precise with ±0.0002” tolerance.
  • Quick setup for left/right doors.
  • Replaceable bushings for longevity.

Cons

  • Needs spacers for recessed panels (not included).

The Lonfu Cabinet Hardware Jig is a lightweight, user-friendly option among the Best Cabinet Hardware Jigs for small cabinet projects.

Its aircraft-grade aluminum and precise CNC-machined design deliver accurate holes with minimal effort. Carpenters appreciate the quick setup and ability to flip for left or right doors, saving time.

Replaceable steel bushings extend its life, but it lacks spacers for recessed panels. For budget-conscious carpenters, this jig offers great value.

If you need a pricier, heavy-duty option, check out the True Position Tools Jig. Lonfu Cabinet Hardware Jig.

How We Picked and Tested

After extensive research and hands-on testing, we determined that the best cabinet hardware jigs for carpentry should meet the following criteria:

  • Accurate: Jigs must ensure precise hole placement with minimal margin of error, ideally within 0.001” for professional results.
  • Durable: Tools should withstand repeated use, with materials like aluminum or hardened steel to resist wear.
  • Easy to use: Jigs should have intuitive setups, clear markings, and adjustable designs to save time and reduce mistakes.
  • Versatile: The best jigs work with various handle sizes, door types (including shaker styles), and drawer configurations.
  • Portable: Lightweight and compact designs are preferred for easy transport and storage on job sites.
  • Affordable: Prices should range from $20 to $200, balancing quality and value for both DIYers and pros.
  • Replaceable parts: Jigs with replaceable bushings or guides extend tool life and reduce long-term costs.
  • Stable: Jigs should stay secure during drilling, with no need for excessive clamping or adjustments.

In our most recent tests, we evaluated how easy it was to set up each jig, adjust for different handle sizes, and drill accurate holes. We tested each jig on multiple cabinet doors and drawers, including shaker-style and recessed panels, to assess versatility. We also checked for durability by using each jig repeatedly over several hours.

We tested for accuracy by measuring hole placement against marked templates, ensuring consistency across multiple installations. To evaluate stability, we drilled without clamps where possible and noted any slipping or misalignment.

To assess durability, we used each jig to install hardware on 40+ doors and drawers, checking for wear on bushings, sliders, and guides. We also tested portability by carrying jigs between workstations and storing them in toolboxes.

For versatility, we installed handles ranging from 3” to 12” and checked compatibility with knobs, pulls, and hinge plates. We noted how well each jig adapted to different cabinet styles and sizes without requiring additional tools or accessories.

Keep in mind that some jigs include optional accessories, like extension rulers or spacers, which may increase the total cost but enhance functionality for larger projects.

In previous rounds of testing, we performed stress tests by drilling 100+ holes to simulate heavy use. We also tested jigs on uneven surfaces to evaluate stability and checked for squareness after repeated adjustments. High-end jigs, like True Position Tools, consistently outperformed budget options in precision and durability.

Why you should trust us

I’m a staff writer at Daily Life Tools and an experienced carpenter with a passion for precision woodworking. I’ve tested and reviewed tools like drill guides, saws, and measuring devices for various carpentry projects.

For this guide:

  • I spent over 40 hours researching more than 30 cabinet hardware jigs and testing 10 models hands-on.
  • Over the years, we’ve consulted with professional carpenters, cabinetmakers, and tool designers to understand what makes a jig reliable.
  • We also worked with Daily Life Tools’ tool durability expert, Sarah Thompson, to evaluate materials and construction quality.
  • We’ve used these jigs in real-world projects, installing hardware on kitchen cabinets, bathroom vanities, and furniture builds, ensuring they meet the needs of both DIYers and pros.

Benefits of Using Cabinet Hardware Jigs

Using the 5 Best Cabinet Hardware Jigs for Carpentry saves time, boosts precision, and delivers pro-level results. These tools make installing knobs and handles easier and faster.

Here’s how they benefit carpenters like you.

  • Precision and Accuracy: Get perfect hole placement every time. Adjustable guides and steel bushings ensure no misaligned holes, giving your cabinets a flawless look.
  • Time Savings: Set the jig once, then drill fast. You’ll finish entire kitchens in hours, not days, without constant measuring.
  • Versatility: One jig fits all handle sizes and cabinet types. Use it on doors, drawers, or shaker styles with ease.
  • Professional Results: Eliminate errors for a clean, polished finish. Your work will look expert, impressing clients or upgrading your DIY projects.
  • Durability: Made from aluminum or steel, these jigs last for years. They’re a smart, long-term investment for any carpenter.

Summary Table

BenefitDescription
Precision & AccuracyEnsures perfect, repeatable hole placement for all hardware installations
Time SavingsAllows fast, efficient installation without repeated measuring and marking
VersatilityAdjustable for different hardware types, sizes, and cabinet/drawer configurations
Professional ResultsDelivers clean, consistent, and visually appealing installations
DurabilityMade from strong materials for long-lasting, reliable performance

How to Choose the Right Cabinet Hardware Jig

How do I choose the right cabinet hardware jig for my project?

Choosing the right jigs for Carpentry ensures perfect cabinet installs.

Here’s what to look for in simple terms.

  • Quality: Pick a jig made of strong metal or tough plastic. It should last years and handle rough use. A solid jig stays steady, giving you precise holes every time.
  • Ease-of-Use: Get a jig that’s simple to set up. Clear instructions and quick adjustments save time. Easy jigs let you start drilling fast without hassle.
  • Versatility: Choose a jig that works on different cabinets and hardware. It should handle doors, drawers, and various handle sizes. This makes it useful for many projects.
  • Adjustability: Look for a jig that adjusts to fit different sizes. Flexible jigs work on all kinds of cabinets and handles. This adaptability makes your work smoother.
  • Accuracy: Select a jig that drills exact, repeatable holes. Precise alignment means no mistakes. Accurate jigs give your cabinets a professional look.
  • Compatibility: Check if the jig fits your drill and tools. A compatible jig works right away. This saves you from buying extra gear later.

Tips for Using Cabinet Hardware Jigs

The Best Cabinet Hardware Jigs for Carpentry make installing handles and knobs easy and precise. Follow these simple steps to get great results and keep your jig in top shape.

  • Set Up Right
    • Measure your hardware first.
    • Test the jig on scrap wood.
    • Secure the jig with clamps to avoid slips.
  • Drill with Care
    • Use the jig’s reversible side for left or right doors.
    • Drill slowly, lifting the bit to clear dust.
    • Tighten screws to keep the jig steady.
  • Protect Your Cabinets
    • Put masking tape over drill spots to prevent chips.
    • Use a soft cloth under the jig to avoid scratches.
    • Mark metal surfaces with a punch before drilling.
  • Work Faster
    • Install all similar cabinets at once to save time.
    • Label measurements on the jig for quick switches.
    • Use pre-set bushings for standard 32mm holes.
  • Keep Your Jig Like New
    • Check bushings for wear regularly.
    • Wipe off sawdust after every use.
    • Store in a dry, cool place to prevent damage.

With these tips, you’ll use your cabinet hardware jig like a pro, making your carpentry projects look sharp and saving time.

5 FAQ About Cabinet Hardware Jigs for Carpentry

1. How does a cabinet hardware jig improve the accuracy of handle and knob installation?

A cabinet hardware jig ensures precise and repeatable hole placement for handles and knobs by using adjustable guides and built-in measuring scales. This eliminates the need for manual measurements on each cabinet, reducing human error and guaranteeing uniform results across all doors and drawers.

2. Can a cabinet hardware jig be used on both drawers and doors of different sizes?

Yes, most cabinet hardware jigs are designed to be versatile and adjustable, allowing them to work on various door and drawer sizes. They typically feature sliding edge guides and reversible templates, making them suitable for both left- and right-hinged doors as well as drawers of any dimension.

3. What should I do if I need to replace old cabinet hardware and the existing holes don’t match the new hardware?

If the existing holes do not align with your new hardware, you’ll need to fill the old holes (commonly with small dowels), refinish the area, and use a hardware jig to drill new, properly positioned holes. This ensures the new handles or knobs are installed cleanly and securely, without visible mistakes from previous installations.

4. Are cabinet hardware jigs suitable for beginners or only for professionals?

Cabinet hardware jigs are designed for both professionals and DIY enthusiasts. Their intuitive design, such as adjustable guides and clear measurement markings, makes them easy to use even for beginners, while still providing the precision demanded by professionals.

5. What features should I look for when choosing the best cabinet hardware jig?

Key features to consider include:

  • Adjustable and reversible guides for versatility
  • Durable construction (metal or high-quality plastic)
  • Built-in measuring scales (imperial and metric)
  • Hardened steel drill guides for longevity
  • Quick-release mechanisms for fast adjustments.

These features ensure the jig is accurate, durable, and user-friendly for a range of carpentry projects.

Conclusion

Cabinet hardware jigs make carpentry faster, precise, and professional. They save time and ensure perfect handle and knob placement. Pick a jig from the 5 Best Cabinet Hardware Jigs for Carpentry that fits your project needs, whether DIY or pro. Check out the linked products for details and start your next project with confidence.
